Reports

Generate, schedule and export IoT data reports in Magistrala as PDF or CSV with timezone and email support.

The Reports Service in Magistrala provides a streamlined way to generate and schedule data reports from connected devices and sensors. It allows users to collect, aggregate, and export metrics in PDF and CSV formats, either via email or direct download.

Architecture

The Reports Service operates through three main components:

Report Configurations: Define what data to collect and how to process it.
Scheduler: Handles recurring report generation based on defined schedules.
Generator Engine: Generates human-readable reports in various formats..

reports_architecture

Reports Service Architecture

Core Concepts Report Configuration

type ReportConfig struct {
    ID          string
    Name        string
    Description string
    DomainID    string
    Config      *MetricConfig
    Metrics     []Metric
    Email       *EmailSetting        // Email Notification settings
    Schedule    Schedule      // Generation schedule
    ReportTemplate ReportTemplate    // Custom HTML template for PDF generation
    Status      Status        // Enabled/Disabled
    CreatedAt   time.Time
    CreatedBy   string
    UpdatedAt   time.Time
    UpdatedBy   string
}

Field	Type	Description	Required
ID	string	Auto-generated unique identifier	Auto
Name	string	Unique report name	✅
Description	string	Report description	Optional
DomainID	string	Domain context identifier	✅
Schedule	Schedule	Execution schedule configuration	✅
Config	MetricConfig	Data collection parameters	✅
Email	EmailSetting	Email distribution settings	Optional
Metrics	[]Metric	List of metrics to include	✅
ReportTemplate	ReportTemplate	Custom HTML template for PDF generation	Optional
Status	Status	Enabled/Disabled state	✅
CreatedAt	time.Time	Creation timestamp	Auto
CreatedBy	string	Creator ID	Auto
UpdatedAt	time.Time	Last update timestamp	Auto
UpdatedBy	string	Last updater ID	Auto

Metric Structure

type Metric struct {
    ChannelID  string  // Source channel for data
    ClientID   string  // Device/sensor identifier
    Name       string  // Metric name (e.g., "temperature", "current")
    Subtopic   string  // Data subtopic filter
    Protocol   string  // Protocol filter (MQTT, HTTP, etc.)
    Format     string
}

Field	Type	Description	Required
ChannelID	string	Source data channel ID	✅
ClientID	string	Specific device/sensor ID	Optional
Name	string	Metric name (e.g., "temperature")	✅
Subtopic	string	Data subtopic filter	Optional
Protocol	string	Protocol filter (MQTT/HTTP/etc.)	Optional
Format	string	Data format specification	Optional

Report Parameters

type MetricConfig struct {
    From        string      // Relative start time (e.g., "now()-24h")
    To          string      // Relative end time (e.g., "now")
    FileFormat  Format      // Optional field
    Timezone    string      // Optional field (IANA timezone name, defaults to UTC)
    Aggregation AggConfig   // Data processing method
}

| Field         | Type      | Description                              | Required |
|---------------|-----------|------------------------------------------|----------|
| From          | string    | Start time (relative/absolute)           | ✅       |
| To            | string    | End time (relative/absolute)             | ✅       |
| FileFormat    | Format    | Output format (PDF/CSV)                  | Optional |
| Timezone      | string    | IANA timezone name ("Europe/Paris")      | Optional |
| Aggregation   | AggConfig | Data processing configuration            | Optional |


type AggConfig struct {
    AggType string  // "SUM", "AVG", "MIN", "MAX", "COUNT"
    Interval string
}

Field	Type	Description	Required
AggType	Aggregation	Processing type (MAX/MIN/SUM/AVG/COUNT)	If aggregation needed
Interval	string	Time window (e.g., "1h", "5m")	If AggType specified

Example configurations

Daily sales report at 8 AM: DAILY + 08:00.
Weekly energy summary every Monday: WEEKLY + 00:00.
Monthly inventory report: MONTHLY + 09:00.

Report Generation

Data Collection

Connects to Magistrala's time-series database.
Collects data using configured:
- Time range (From/To).
- Aggregation method.
- Metric filters.
Supports complex queries across multiple devices and channels.

Timezone Support

The Reports Service supports timezone-aware report generation using IANA timezone names. This feature allows timestamps in generated reports to be displayed in the user's preferred timezone rather than UTC.

Key Features:

Supports all IANA timezone names (e.g., "Europe/Paris", "America/New_York", "Asia/Tokyo")
Defaults to UTC when no timezone is specified
Automatically applies the timezone to:
- Report generation timestamps (header and footer)
- All message timestamps in both PDF and CSV formats
Falls back to UTC gracefully if an invalid timezone is provided

Example Timezone Values:

"America/New_York" - Eastern Time (US)
"Europe/London" - British Time
"Asia/Tokyo" - Japan Standard Time
"Australia/Sydney" - Australian Eastern Time
"" or omitted - Defaults to UTC

Note: The timezone field is optional and can be included in the config section of any report configuration or generation request.

Output Formats

Both PDF and CSV formats contain identical data - they differ only in presentation style and file structure:

Feature	PDF Format	CSV Format
Structure	Multi-page document with tables	Single-file comma-separated values
Headers	Styled section headers	Simple text row headers
Data Format	Human-readable timestamps	Human-readable timestamps
Visual Elements	Page numbers, borders, shading	Plain text with commas
Best For	Printing/sharing	Programmatic analysis

Example Data Representation

PDF Table:

Time	Value	Unit	Protocol	Subtopic
2024-03-15 09:30:00	23.4	°C	http	room1
2024-03-15 09:35:00	45.2	°C	http	room1

Equivalent CSV:

Timestamp,Value,Unit,Protocol,Subtopic
2024-03-15T09:30:00Z,23.4,°C,http,room1
2024-03-15T09:35:00Z,45.2,°C,http,room1

Email Integration

type EmailSetting struct {
    To      []string  // Recipient addresses
    Subject string    // Email subject line
}

Field	Type	Description	Required
To	[]string	Recipient email addresses	✅
Subject	string	Email subject line	Optional
Content	string	Email body content	Optional

NOTE: Automatically sends generated reports via email, including a summary of the report contents in the body.

Report Templates

The Reports Service supports custom HTML templates for PDF generation, allowing you to customize the appearance and layout of your reports. Templates use Go's standard html/template package and provide fine-grained control over report formatting.

Template Structure

type ReportTemplate string

func (temp ReportTemplate) Validate() error
func (temp ReportTemplate) String() string
func (temp ReportTemplate) MarshalJSON() ([]byte, error)
func (temp *ReportTemplate) UnmarshalJSON(data []byte) error

A template is a string containing HTML with embedded template variables and control structures. The template system validates all templates against required structure and fields before allowing their use.

Required Template Components

The template validation system uses a tiered approach to give users maximum control while ensuring PDF generation works correctly:

HTML Structure Requirements

Element	Description	Required
`<!DOCTYPE html>`	HTML5 document type declaration	✅
`<html>`	Root HTML element	✅
`<head>`	Document head section	✅
`<body>`	Document body section	✅
`<style>`	CSS styling section	✅

Essential Template Variables (Required)

These fields are absolutely necessary for PDF generation:

Variable	Description	Usage Example
`{{$.Title}}`	Report title	`<title>{{$.Title}}</title>`
`{{range .Messages}}...{{end}}`	Message iteration block	`{{range .Messages}}<tr>...</tr>{{end}}`
`{{formatTime .Time}}`	Formatted timestamp	`<td>{{formatTime .Time}}</td>`
`{{formatValue .}}`	Formatted message value	`<td>{{formatValue .}}</td>`

Recommended Template Variables (Optional)

These fields enhance the report but are not strictly required:

Variable	Description	Usage Example
`{{$.GeneratedDate}}`	Generation date	`<div>{{$.GeneratedDate}}</div>`
`{{$.GeneratedTime}}`	Generation time	`<span>{{$.GeneratedTime}}</span>`
`{{.Metric.Name}}`	Metric name	`<td>{{.Metric.Name}}</td>`
`{{.Metric.ChannelID}}`	Channel identifier	`<td>{{.Metric.ChannelID}}</td>`
`{{len .Messages}}`	Message count	`<span>{{len .Messages}}</span>`

Conditional Template Variables (Use if Needed)

These fields are only required if your data uses them:

Variable	Description	When Required
`{{.Metric.ClientID}}`	Device/client identifier	When filtering by specific devices
`{{.Unit}}`	Value unit	When measurements have units
`{{.Protocol}}`	Protocol type	When protocol filtering is used
`{{.Subtopic}}`	Message subtopic	When subtopic filtering is used

Essential CSS Classes (Required)

CSS Class	Description	Purpose
`.page`	Page container	Main page layout and styling
`.data-table`	Data table styling	Table layout and formatting

Recommended CSS Classes (Optional)

CSS Class	Description	Purpose
`.header`	Header section	Report header area
`.content-area`	Main content area	Primary content container
`.metrics-section`	Metrics information section	Metrics overview display
`.footer`	Footer section	Report footer area

Required Table Elements (Only if using `.data-table`)

Element	Description	Purpose
`<table>`	Table container	Main table structure
`<thead>`	Table header section	Column headers
`<tbody>`	Table body section	Data rows
`<th>`	Table header cells	Column header definitions
`<td>`	Table data cells	Individual data values

Template Data Structure

Templates receive the following data structure:

type ReportData struct {
    Title         string    // Report title
    GeneratedTime string    // Generation time (HH:MM:SS format)
    GeneratedDate string    // Generation date (DD MMM YYYY format)
    Reports       []Report  // Array of report data
}

type Report struct {
    Metric   Metric          // Metric information
    Messages []senml.Message // Sensor data messages
}

type Metric struct {
    ChannelID string // Source channel ID
    ClientID  string // Device/sensor ID
    Name      string // Metric name
    Subtopic  string // Message subtopic
    Protocol  string // Protocol used
    Format    string // Data format
}

Template Functions

Templates have access to these custom functions:

Function	Purpose	Usage
`formatTime`	Format Unix timestamp	`{{formatTime .Time}}`
`formatValue`	Format message value	`{{formatValue .}}`
`add`	Add two integers	`{{add $a $b}}`
`sub`	Subtract two integers	`{{sub $a $b}}`

Template Management API

Create/Update Report Template

Update a custom template for a specific report configuration:

curl --location --request PUT 'http://localhost:9008/domains/{domainID}/reports/configs/{reportID}/template' \
--header 'Content-Type: application/json' \
--header 'Authorization: Bearer $ACCESSTOKEN' \
--data '{
    "report_template": "<!DOCTYPE html><html><head><style>.page{...}.header{...}</style></head><body>{{range .Reports}}<div class=\"page\">...</div>{{end}}</body></html>"
}'

View Report Template

Retrieve the current template for a report configuration:

curl --location 'http://localhost:9008/domains/{domainID}/reports/configs/{reportID}/template' \
--header 'Authorization: Bearer $ACCESSTOKEN'

Response:

{
    "template": "<!DOCTYPE html><html>..."
}

Delete Report Template

Remove a custom template (reverts to default):

curl --location --request DELETE 'http://localhost:9008/domains/{domainID}/reports/configs/{reportID}/template' \
--header 'Authorization: Bearer $ACCESSTOKEN'

Template Usage in Reports

Templates can be used in two ways:

Configuration-level Template: Set a custom template for a specific report configuration.
Request-level Template: Include a template in individual report generation requests.

Configuration-level Usage

curl --location 'http://localhost:9008/domains/{domainID}/reports/configs' \
--header 'Content-Type: application/json' \
--header 'Authorization: Bearer $ACCESSTOKEN' \
--data '{
    "name": "Custom Template Report",
    "description": "Report with custom template",
    "config": {
        "from": "now()-24h",
        "to": "now()",
        "title": "Daily Temperature Report"
    },
    "metrics": [...],
    "report_template": "<!DOCTYPE html>..."
}'

Request-level Usage

curl --location 'http://localhost:9008/domains/{domainID}/reports?action=download' \
--header 'Content-Type: application/json' \
--header 'Authorization: Bearer $ACCESSTOKEN' \
--data '{
    "name": "Temp Report",
    "config": {
        "from": "now()-24h",
        "to": "now()",
        "file_format": "pdf",
        "title": "Temperature Analysis"
    },
    "metrics": [...],
    "report_template": "<!DOCTYPE html>..."
}'

Template Example

Here's a complete working template that demonstrates all required elements:

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width,initial-scale=1.0">
    <title>{{$.Title}}</title>
    <style>
        /* CSS Variables for consistent theming */
        :root {
            --primary-color: #0066cc;
            --secondary-color: #004499;
            --accent-color: #ff6b35;
            /* ... additional CSS variables ... */
        }

        /* Required CSS Classes */
        .page {
            max-width: 210mm;
            min-height: 297mm;
            background: var(--white);
            display: flex;
            flex-direction: column;
            /* ... additional styling ... */
        }

        .header {
            height: var(--header-height);
            position: relative;
            flex-shrink: 0;
            /* ... header styling ... */
        }

        .content-area {
            flex-grow: 1;
            display: flex;
            flex-direction: column;
            /* ... content styling ... */
        }

        .metrics-section {
            margin-bottom: 20px;
            /* ... metrics styling ... */
        }

        .data-table {
            width: 100%;
            border-collapse: collapse;
            /* ... table styling ... */
        }

        .footer {
            height: var(--footer-height);
            border-top: 3px solid var(--subtle-color);
            /* ... footer styling ... */
        }
    </style>
</head>
<body>
    {{$totalPages := len .Reports}}
    {{$globalPage := 0}}
    {{range $index, $report := .Reports}}
    {{$globalPage = add $globalPage 1}}

    <div class="page">
        <div class="header">
            <div class="header-content">
                <div class="header-logo">MAGISTRALA</div>
                <div class="header-title">{{$.Title}}</div>
                <div class="header-date">{{$.GeneratedDate}}</div>
            </div>
        </div>

        <div class="content-area">
            <div class="metrics-section">
                <div class="metrics-info">
                    <div class="metric-row">
                        <div class="metric-label">Name:</div>
                        <div class="metric-value">{{.Metric.Name}}</div>
                    </div>
                    {{if .Metric.ClientID}}
                    <div class="metric-row">
                        <div class="metric-label">Device ID:</div>
                        <div class="metric-value">{{.Metric.ClientID}}</div>
                    </div>
                    {{end}}
                    <div class="metric-row">
                        <div class="metric-label">Channel ID:</div>
                        <div class="metric-value">{{.Metric.ChannelID}}</div>
                    </div>
                </div>
            </div>

            <div class="record-count">
                Total Records: {{len .Messages}}
            </div>

            <div class="table-container">
                <table class="data-table">
                    <thead>
                        <tr>
                            <th class="col-time">Time</th>
                            <th class="col-value">Value</th>
                            <th class="col-unit">Unit</th>
                            <th class="col-protocol">Protocol</th>
                            <th class="col-subtopic">Subtopic</th>
                        </tr>
                    </thead>
                    <tbody>
                        {{range .Messages}}
                        <tr>
                            <td class="col-time">{{formatTime .Time}}</td>
                            <td class="col-value">{{formatValue .}}</td>
                            <td class="col-unit">{{.Unit}}</td>
                            <td class="col-protocol">{{.Protocol}}</td>
                            <td class="col-subtopic">{{.Subtopic}}</td>
                        </tr>
                        {{end}}
                    </tbody>
                </table>
            </div>
        </div>

        <div class="footer">
            <div class="footer-content">
                <div class="footer-generated">Generated: {{$.GeneratedTime}}</div>
                <div class="footer-page">Page {{$globalPage}} of {{$totalPages}}</div>
            </div>
        </div>
    </div>
    {{end}}
</body>
</html>

Minimal Template Example

For users who want maximum control and minimal requirements, here's the absolute minimal template:

<!DOCTYPE html>
<html>
<head>
    <title>{{$.Title}}</title>
    <style>
        .page {
            padding: 20px;
            font-family: Arial, sans-serif;
        }
        .data-table {
            width: 100%;
            border-collapse: collapse;
            border: 1px solid #ccc;
        }
        .data-table th, .data-table td {
            border: 1px solid #ccc;
            padding: 8px;
            text-align: left;
        }
        .data-table th {
            background-color: #f5f5f5;
        }
    </style>
</head>
<body>
    {{range .Reports}}
    <div class="page">
        <h1>{{$.Title}}</h1>

        <table class="data-table">
            <thead>
                <tr>
                    <th>Time</th>
                    <th>Value</th>
                </tr>
            </thead>
            <tbody>
                {{range .Messages}}
                <tr>
                    <td>{{formatTime .Time}}</td>
                    <td>{{formatValue .}}</td>
                </tr>
                {{end}}
            </tbody>
        </table>
    </div>
    {{end}}
</body>
</html>

This minimal template includes only:

✅ HTML structure (<!DOCTYPE html>, <html>, <head>, <body>, <style>).
✅ Essential variables ({{$.Title}}, {{range .Messages}}, {{formatTime .Time}}, {{formatValue .}}, {{end}}).
✅ Essential CSS classes (.page, .data-table).
✅ Basic table structure (<table>, <thead>, <tbody>, <th>, <td>).

Template Breakdown

This example demonstrates how all required elements work together:

1. HTML Structure Requirements ✅

<!DOCTYPE html>        <!-- Required DOCTYPE -->
<html lang="en">       <!-- Required html tag -->
<head>                 <!-- Required head section -->
<style>                <!-- Required style section -->
<body>                 <!-- Required body tag -->

2. Required Template Variables ✅

{{$.Title}} - Used in <title> and header section.
{{$.GeneratedDate}} - Displayed in header date area.
{{$.GeneratedTime}} - Shown in footer.
{{.Metric.Name}} - Metric name in info section.
{{.Metric.ClientID}} - Device ID (with conditional display).
{{.Metric.ChannelID}} - Channel ID in info section.
{{len .Messages}} - Record count display.
{{range .Messages}}...{{end}} - Iterates through data.
{{formatTime .Time}} - Formats timestamps.
{{formatValue .}} - Formats values.
{{.Unit}}, {{.Protocol}}, {{.Subtopic}} - Data fields.

3. Required CSS Classes ✅

.page - Main page container with layout properties.
.header - Header section styling.
.content-area - Main content area with flex layout.
.metrics-section - Metrics information styling.
.data-table - Table styling and layout.
.footer - Footer section positioning.

4. Required Table Elements ✅

<table class="data-table">    <!-- Table container -->
  <thead>                     <!-- Table header -->
    <tr>
      <th>Time</th>           <!-- Required headers -->
      <th>Value</th>
      <th>Unit</th>
      <th>Protocol</th>
      <th>Subtopic</th>
    </tr>
  </thead>
  <tbody>                     <!-- Table body -->
    <tr>
      <td>{{formatTime .Time}}</td>  <!-- Data cells -->
      <td>{{formatValue .}}</td>
      <!-- ... more cells ... -->
    </tr>
  </tbody>
</table>

5. Template Functions Usage ✅

{{add $globalPage 1}} - Increment page counter.
{{formatTime .Time}} - Format Unix timestamps.
{{formatValue .}} - Format message values.
{{len .Messages}} - Count messages.

6. Template Control Structures ✅

{{range $index, $report := .Reports}}    <!-- Loop through reports -->
  {{$globalPage = add $globalPage 1}}    <!-- Variable assignment -->

  {{if .Metric.ClientID}}               <!-- Conditional display -->
    <div>{{.Metric.ClientID}}</div>
  {{end}}

  {{range .Messages}}                   <!-- Nested loop for messages -->
    <tr>...</tr>
  {{end}}
{{end}}                                 <!-- Properly closed blocks -->

Advanced Features Demonstrated

CSS Custom Properties: Using CSS variables for consistent theming.
Responsive Design: Viewport meta tag and flexible layouts.
Print Optimization: @media print styles for PDF generation.
Visual Enhancements: Gradients, shadows, and modern styling.
Conditional Content: Using {{if}} to show optional fields.
Page Counting: Variable manipulation for page numbers.

Template Validation

The system performs comprehensive validation on report templates to ensure they can generate valid PDF reports. The validation process uses Go's template parser to check both syntax and required fields.

Template Validation Process

When a template is provided (either during report config creation, template update, or report generation), the system validates:

Template Syntax: Uses Go's text/template parser to verify the template has valid Go template syntax
Essential Fields: Ensures all required template variables and control structures are present
Template Structure: Validates that template blocks are properly opened and closed

Required Template Elements

The following elements are mandatory for template validation to pass:

1. Essential Template Variables

{{$.Title}} - Report title (must be present somewhere in the template)
{{range .Messages}} - Loop structure to iterate through message data
{{formatTime .Time}} - Function to format message timestamps
{{formatValue .}} - Function to format message values
{{end}} - Closing tag for the range block

2. Template Control Structures

All {{range}} blocks must have corresponding {{end}} tags
All {{if}} blocks must have corresponding {{end}} tags
All {{with}} blocks must have corresponding {{end}} tags

Common Validation Errors

Error Type	Description	Example	Solution
Template syntax error	Invalid Go template syntax	`{{range .Messages"}}` (missing closing `}}`)	Fix template syntax: `{{range .Messages}}`
Missing essential field: $.Title	Template lacks title variable	Template without `{{$.Title}}`	Add `{{$.Title}}` somewhere in template
Missing essential field: range .Messages	Template lacks message iteration	No `{{range .Messages}}` block	Add `{{range .Messages}}`...`{{end}}` block
Missing essential field: formatTime .Time	Template lacks time formatting	No `{{formatTime .Time}}` in range block	Add `{{formatTime .Time}}` inside messages range
Missing essential field: formatValue .	Template lacks value formatting	No `{{formatValue .}}` in range block	Add `{{formatValue .}}` inside messages range
Missing essential field: end	Template lacks proper block closure	`{{range .Messages}}` without `{{end}}`	Ensure all blocks are properly closed

Validation Examples

✅ Valid minimal template:

<!DOCTYPE html>
<html>
<head><title>{{$.Title}}</title></head>
<body>
  <h1>{{$.Title}}</h1>
  {{range .Messages}}
    <p>Time: {{formatTime .Time}}, Value: {{formatValue .}}</p>
  {{end}}
</body>
</html>

❌ Invalid template (missing formatTime):

<!DOCTYPE html>
<html>
<head><title>{{$.Title}}</title></head>
<body>
  <h1>{{$.Title}}</h1>
  {{range .Messages}}
    <p>Value: {{formatValue .}}</p>  <!-- Missing formatTime .Time -->
  {{end}}
</body>
</html>

❌ Invalid template (syntax error):

<!DOCTYPE html>
<html>
<head><title>{{$.Title}}</title></head>
<body>
  <h1>{{$.Title}}</h1>
  {{range .Messages}}
    <p>Time: {{formatTime .Time}}, Value: {{formatValue .}}</p>
  {{end  <!-- Missing closing }} -->
</body>
</html>

When Validation Occurs

Template validation is performed during:

Report Config Creation (POST /configs) - If report_template field is provided
Template Update (PUT /configs/{reportID}/template) - Always validates the new template
Report Generation (POST /) - If report_template field is provided in the request

If validation fails, the API returns HTTP 400 with a descriptive error message indicating what's missing or incorrect.

Optional vs Required Elements

The validation focuses only on elements absolutely necessary for report generation. The following are optional and not validated:

HTML structure (DOCTYPE, html, head, body tags)
CSS styling and classes
Additional template variables like {{$.GeneratedDate}}, {{.Metric.Name}}, etc.
Table structures and formatting
Custom functions beyond formatTime and formatValue

This approach gives developers maximum flexibility while ensuring the core functionality works correctly.

Default Template

If no custom template is provided, the system uses a built-in default template that includes:

Professional styling with corporate color scheme.
Responsive layout optimized for PDF generation.
Automatic page breaks for multi-metric reports.
Header and footer sections with metadata.
Sortable data tables with alternating row colors.

Best Practices

Start with the default template as a reference for required structure.
Test template validation before using in production.
Use semantic CSS classes for maintainable styling.
Consider PDF constraints when designing layouts.
Include proper error handling for missing data fields.
Validate template blocks are properly closed.

API Operations

Base URL: http://localhost:9008/{domainID}/reports

Create Report Configuration

Endpoint: POST /configs

curl --location http://localhost:9008/domains/{domainID}/reports/configs \
--header 'Content-Type: application/json' \
--header 'Authorization: Bearer $ACCESSTOKEN' \
--data '{
    "name": "lab 1 report",
    "description": "lab 1 sensors report",
    "config": {
        "from": "now()-5d",
        "to": "now()",
        "timezone": "America/New_York",
        "aggregation": {
            "agg_type":"MAX",
            "interval":"1s"
        }
    },
    "metrics": [
        {
            "channel_id": "{{CHANNELID}}",
            "client_id": "{{THINGID}}",
            "name": "current",
            "subtopic": "lab/room1"
        }
    ]
    "schedule": {
        "start_datetime": "2025-04-28T00:00:00.000Z",
        "time": "0001-01-01T20:30:00.000Z",
        "recurring": "daily",
        "recurring_period": 1
    },
    "email": {
        "to": ["team@example.com"],
        "subject": "Weekly Lab Report"
    },
    "report_template": "<!DOCTYPE html><html>...</html>"
}'

Note: The report_template field is optional. If provided, it must contain valid HTML with all required template elements. If omitted, the default template will be used.

Expected response:

{
    "id": "daebc977-60a6-49f9-8f9f-200474a8c697",
    "name": "lab report",
    "description": "lab 1 report",
    "domain_id": "88c2bc9a-ce3b-4dfc-804d-219177cb9a75",
    "schedule": {
        "start_datetime": "2025-04-28T00:00:00Z",
        "time": "0001-01-01T20:30:00Z",
        "recurring": "daily",
        "recurring_period": 1
    },
    "config": {
        "from": "now()-5d",
        "to": "now()",
        "timezone": "America/New_York",
        "aggregation": {
            "agg_type": "max",
            "interval": "1s"
        }
    },
    "email": {
        "to": [
            "team@example.com"
        ],
        "subject": "Weekly Lab Report"
    },
    "metrics": [
        {
            "channel_id": "f0e052ce-ef01-49b9-862c-2ecbc911f0a1",
            "client_id": "69a9b488-523a-4805-aae9-123febaf83f5",
            "name": "current",
            "format": ""
        }
    ],
    "status": "enabled",
    "created_at": "2025-04-28T12:59:13.768526Z",
    "created_by": "14c2a388-310d-402b-ad8e-8c0b7d9f81f1",
    "updated_at": "0001-01-01T00:00:00Z"
}

Generate Report Endpoint: POST /

curl -X POST http://localhost:9008/domains/{domainID}/reports \
--header 'Content-Type: application/json' \
--header 'Authorization: Bearer $ACCESSTOKEN' \
--data '{
    "name": "lab 1 report",
    "description": "lab 1 sensors report",
    "config": {
        "from": "now()-5d",
        "to": "now()",
        "timezone": "Europe/London",
        "aggregation": {
            "agg_type":"MAX",
            "interval":"1s"
        }
    },
    "metrics": [
        {
            "channel_id": "{{CHANNELID}}",
            "client_id": "{{THINGID}}",
            "name": "current"
            "subtopic": "lab/room1"
        }
    ]
}'

Expected response:

{
    "total": 1,
    "from": "2025-04-23T08:57:29.23737193Z",
    "to": "2025-04-28T08:57:29.237409661Z",
    "aggregation": {},
    "reports": [
        {
            "metric": {
                "channel_id": "a246bea7-dc05-49f1-bb61-c08c44a7df33",
                "client_id": "e2ab8673-8599-435f-8d42-62903d279492",
                "name": "current",
                "format": ""
            },
            "messages": [
                {
                    "subtopic": "lab/room1",
                    "protocol": "http",
                    "name": "current",
                    "unit": "A",
                    "time": 1276020072001000000,
                    "value": 1.33
                },
                {
                    "subtopic": "lab/room1",
                    "protocol": "http",
                    "name": "current",
                    "unit": "A",
                    "time": 1276020071001000000,
                    "value": 1.5
                }
            ]
        }
    ]
}

Note: This API can be used to configure multiple actions and download reports. The available actions are view, download and email. The default action is view. To change the action you can pass the action parameter:

curl --location 'http://localhost:9008/bd1bb2c5-ce78-4456-8725-bd1beab80250/reports?action=download' \
--header 'Content-Type: application/json' \
--header 'Authorization: Bearer $ACCESSTOKEN' \
--data '{
    "name": "lab 1 report",
    "description": "lab 1 sensors report",
    "config": {
        "from": "now()-5d",
        "to": "now()",
        "file_format": "pdf",
        "timezone": "Asia/Tokyo"
    },
    "metrics": [
        {
            "channel_id": "a246bea7-dc05-49f1-bb61-c08c44a7df33",
            "client_id": "e2ab8673-8599-435f-8d42-62903d279492",
            "name": "current"
        }
    ]
}'

Expected response:

report_pdf

Note: The supported formats are csv and pdf which are set in the config field.

To send the generated report via email it can be done as follows:

curl --location 'http://localhost:9008/bd1bb2c5-ce78-4456-8725-bd1beab80250/reports?action=email' \
--header 'Content-Type: application/json' \
--header 'Authorization: Bearer $ACCESSTOKEN' \
--data-raw '{
    "name": "lab 1 report",
    "description": "lab 1 sensors report",
    "config": {
        "from": "now()-5d",
        "to": "now()",
        "file_format": "pdf",
        "timezone": "Australia/Sydney"
    },
    "metrics": [
        {
            "channel_id": "a246bea7-dc05-49f1-bb61-c08c44a7df33",
            "client_id": "e2ab8673-8599-435f-8d42-62903d279492",
            "name": "current"
        }
    ],
     "email":{
        "to": ["team@example.com"],
        "subject": "Weekly Lab Report"
    }
}'

List Report Configurations Endpoint: GET /configs

curl "http://localhost:9008/domains/{domainID}/reports/configs?status=enabled&limit=10" \
--header 'Authorization: Bearer $ACCESSTOKEN'

Expected response:

{
    "limit": 10,
    "offset": 0,
    "total": 1,
    "report_configs": [
        {
            "id": "daebc977-60a6-49f9-8f9f-200474a8c697",
            "name": "lab report",
            "description": "lab 1 report",
            "domain_id": "88c2bc9a-ce3b-4dfc-804d-219177cb9a75",
            "schedule": {
                "start_datetime": "2025-04-28T00:00:00Z",
                "time": "0001-01-01T20:30:00Z",
                "recurring": "daily",
                "recurring_period": 1
            },
            "config": {
                "from": "now()-5d",
                "to": "now()",
                "aggregation": {
                    "agg_type": "max",
                    "interval": "1s"
                }
            },
            "email": {
                "to": [
                    "team@example.com"
                ],
                "subject": "Weekly Lab Report"
            },
            "metrics": [
                {
                    "channel_id": "f0e052ce-ef01-49b9-862c-2ecbc911f0a1",
                    "client_id": "69a9b488-523a-4805-aae9-123febaf83f5",
                    "name": "current",
                    "format": ""
                }
            ],
            "status": "enabled",
            "created_at": "2025-04-28T12:59:13.768526Z",
            "created_by": "14c2a388-310d-402b-ad8e-8c0b7d9f81f1",
            "updated_at": "0001-01-01T00:00:00Z"
        }
    ]
}

Note : The following parameters are supported status, limit, offset and name. This allows for search by name

View report configurations Endpoint: GET /configs/{reportID}

curl --location 'http://localhost:9008/{domainID}/reports/configs/{reportID}' \
--header 'Authorization: Bearer $TOKEN'

Enable Report Configuration Activate a scheduled report configuration.

Endpoint: POST /{domainID}/reports/configs/{reportID}/enable

curl --location http://localhost:9008/domains/{domainID}/reports/configs/{reportID}/enable \
--header 'Authorization: Bearer $ACCESSTOKEN'

Disable Report Configuration Pause a scheduled report generation.

Endpoint: POST /{domainID}/reports/configs/{reportID}/disable

curl --location http://localhost:9008/domains/{domainID}/reports/configs/{reportID}/disable \
--header 'Authorization: Bearer $ACCESSTOKEN'

Update Report Configuration Modify an existing report configuration.

Endpoint: PATCH /{domainID}/reports/configs/{reportID}

curl --location --request PATCH 'http://localhost:9008/domains/{domainID}/reports/configs/{reportID}' \
--header 'Content-Type: application/json' \
--header 'Authorization: Bearer $ACCESSTOKEN' \
--data '{
    "name": "Updated Environment Report",
    "schedule": {
        "start_datetime": "2025-04-07T00:00:00.000Z",
        "time": "0001-01-01T00:00:00.000Z",
        "recurring": "daily",
        "recurring_period": 1
    }
}'

Update Report Template Update the custom HTML template for a report configuration.

Endpoint: PUT /{domainID}/reports/configs/{reportID}/template

curl --location --request PUT 'http://localhost:9008/domains/{domainID}/reports/configs/{reportID}/template' \
--header 'Content-Type: application/json' \
--header 'Authorization: Bearer $ACCESSTOKEN' \
--data '{
    "report_template": "<!DOCTYPE html><html><head><style>...</style></head><body>...</body></html>"
}'

View Report Template Retrieve the current template for a report configuration.

Endpoint: GET /{domainID}/reports/configs/{reportID}/template

curl --location 'http://localhost:9008/domains/{domainID}/reports/configs/{reportID}/template' \
--header 'Authorization: Bearer $ACCESSTOKEN'

Delete Report Template Remove a custom template (reverts to default template).

Endpoint: DELETE /{domainID}/reports/configs/{reportID}/template

curl --location --request DELETE 'http://localhost:9008/domains/{domainID}/reports/configs/{reportID}/template' \
--header 'Authorization: Bearer $ACCESSTOKEN'

On this page
